MAB1683 Anti-Ankyrin Antibody, clone Ank016

MAB1683
50 µg
Purchase on Sigma-Aldrich

Speciální nabídky

Přehled

Replacement Information

Speciální nabídky

Tabulka spec. kláve

Species ReactivityKey ApplicationsHostFormatAntibody Type
B, Ca, H, M, Po, R, RbELISA, FC, IP, WB, ICCMPurifiedMonoclonal Antibody
Description
Catalogue NumberMAB1683
Brand Family Chemicon®
Trade Name
  • Chemicon
DescriptionAnti-Ankyrin Antibody, clone Ank016
References
Product Information
FormatPurified
PresentationPurified immunoglobulin from culture supernatant. Liquid in 10 mM sodium phosphate, pH 7.5 and 150mM NaCl with 0.01% NaN3.
Quality LevelMQ100
Applications
ApplicationAnti-Ankyrin Antibody, clone Ank016 is an antibody against Ankyrin for use in ELISA, FC, IP, WB & IC.
Key Applications
  • ELISA
  • Flow Cytometry
  • Immunoprecipitation
  • Western Blotting
  • Immunocytochemistry
Application NotesWestern blotting at 1:200; low percentage PAGE gels a must; protein is quite large; proteinase inhibitors recommended or lower level fragments likely; membrane preparations and enhance signals.

ELISA: 1:1000

Immunoprecipitation: 1:100

Immunocytochemistry, using 2% paraformaldehyde fixation; higher fixation (i.e. 4% PFA can be problematic) 1:100; light fixation 5-10' RT usually; permeabilize lightly with 0.1% triton X-100 as protein is intracellular.

Flow cytometry: 1:500

Immunohistochemistry: 1:100; light fixations suggested; PLP or mild zinc formalin recommended.

RIA: 1:5000

Optimal working dilutions must be determined by end user.
Biological Information
ImmunogenPurified human erythroid cells ankyrin
CloneAnk016
ConcentrationPlease refer to the Certificate of Analysis for the lot-specific concentration.
HostMouse
SpecificityReacts with the intracellular ankyrin (216 kDa). Ankyrin consists of a single peptide of M.W. 215 kDa known to be involved in the attachment of spectrin containing membrane skeleton to the plasma membranes. Ankyrin belongs to a family of closely related polypeptides associated with the plasma membrane of cells in a variety of cell types (e.g., lymphocytes, platelets, fibroblasts and endothelial cells) and various tissues (e.g., brain, kidney, muscle and many epithelial tissues).
IsotypeIgG2a
Species Reactivity
  • Bovine
  • Canine
  • Human
  • Mouse
  • Pig
  • Rat
  • Rabbit
Antibody TypeMonoclonal Antibody
Entrez Gene Number
Entrez Gene SummaryAnkyrins are a family of proteins that are believed to link the integral membrane proteins to the underlying spectrin-actin cytoskeleton and play key roles in activities such as cell motility, activation, proliferation, contact and the maintenance of specialized membrane domains. Multiple isoforms of ankyrin with different affinities for various target proteins are expressed in a tissue-specific, developmentally regulated manner. Most ankyrins are typically composed of three structural domains: an amino-terminal domain containing multiple ankyrin repeats; a central region with a highly conserved spectrin binding domain; and a carboxy-terminal regulatory domain which is the least conserved and subject to variation. Ankyrin 1, the prototype of this family, was first discovered in the erythrocytes, but since has also been found in brain and muscles. Mutations in erythrocytic ankyrin 1 have been associated in approximately half of all patients with hereditary spherocytosis. Complex patterns of alternative splicing in the regulatory domain, giving rise to different isoforms of ankyrin 1 have been described, however, the precise functions of the various isoforms are not known. Alternative polyadenylation accounting for the different sized erythrocytic ankyrin 1 mRNAs, has also been reported. Truncated muscle-specific isoforms of ankyrin 1 resulting from usage of an alternate promoter have also been identified.
Gene Symbol
  • ANK1
  • ANK
  • SPH2
  • SPH1
  • Ankyrin-R
  • Ankyrin-1
  • ankyrin-R
UniProt Number
UniProt SummaryFUNCTION: SwissProt: P16157 # Attaches integral membrane proteins to cytoskeletal elements; binds to the erythrocyte membrane protein band 4.2, to Na-K ATPase, to the lymphocyte membrane protein GP85, and to the cytoskeletal proteins fodrin, tubulin, vimentin and desmin. Erythrocyte ankyrins also link spectrin (beta chain) to the cytoplasmic domain of the erythrocytes anion exchange protein; they retain most or all of these binding functions. In skeletal muscle, isoform Mu17 together with obscurin may provide a molecular link between the sarcoplasmic reticulum and myofibrils.
SIZE: 1881 amino acids; 206265 Da
SUBUNIT: Interacts with a number of integral membrane proteins and cytoskeletal proteins. Binds SPTB/spectrin (beta chain) through a 70 AA N-terminal region of the 62 kDa domain, and the C-terminal of SLC4A1/erythrocyte membrane protein band 3 through the ankyrin repeat region. Also interacts with TTN/titin. Isoform Mu17 interacts with OBSCN isoform 3/obscurin.
SUBCELLULAR LOCATION: Isoform Er1: Cytoplasm. Note=Probably the other erythrocyte (Er) isoforms, are located near the surface of erythrocytic plasma membrane. & Isoform Mu17: Membrane. Cytoplasm, myofibril, sarcomere, M-band. Note=Colocalizes with OBSCN isoform 3/obscurin at the M line in differentiated skeletal muscle cells. & Isoform Mu18: Sarcoplasmic reticulum (Probable). & Isoform Mu19: Sarcoplasmic reticulum (Probable). & Isoform Mu20: Sarcoplasmic reticulum (Probable).
TISSUE SPECIFICITY: Isoform Mu17, isoform Mu18,isoform Mu19 and isoform Mu20 are expressed in skeletal muscle. Isoform Br21 is expressed in brain.
DOMAIN: SwissProt: P16157 The 55 kDa regulatory domain is involved in regulating binding of SPTB/spectrin (beta chain) and SLC4A1/erythrocyte membrane protein band 3. & The ANK repeat region forms a spiral around a large central cavity and is involved in binding of ion transporters.
PTM: Regulated by phosphorylation. & Palmitoylated.DISEASE:SwissProt: P16157 # Defects in ANK1 are a cause of hereditary spherocytosis (HS) [MIM:182900]. Inheritance can be autosomal dominant or recessive.
SIMILARITY: Contains 23 ANK repeats. & Contains 1 death domain. & Contains 1 ZU5 domain.
Physicochemical Information
Dimensions
Materials Information
Toxicological Information
Safety Information according to GHS
Safety Information
Product Usage Statements
Usage Statement
  • Unless otherwise stated in our catalog or other company documentation accompanying the product(s), our products are intended for research use only and are not to be used for any other purpose, which includes but is not limited to, unauthorized commercial uses, in vitro diagnostic uses, ex vivo or in vivo therapeutic uses or any type of consumption or application to humans or animals.
Storage and Shipping Information
Storage ConditionsMaintain at -20°C in undiluted aliquots for up to 12 months after date of receipt. Avoid repeated freeze/thaw cycles.
Packaging Information
Material Size50 µg
Transport Information
Supplemental Information
Specifications
Global Trade Item Number
Katalogové číslo GTIN
MAB1683 04053252505430

Documentation

Anti-Ankyrin Antibody, clone Ank016 MSDS

Title

Safety Data Sheet (SDS)

Anti-Ankyrin Antibody, clone Ank016 Certificates of Analysis

TitleLot Number
MOUSE ANTI-ANKYRIN - 3848471 3848471
MOUSE ANTI-ANKYRIN -2569698 2569698
MOUSE ANTI-ANKYRIN -2809303 2809303
MOUSE ANTI-ANKYRIN MONOCLONAL ANTIBODY 3170220
MOUSE ANTI-ANKYRIN MONOCLONAL ANTIBODY 2955433
MOUSE ANTI-ANKYRIN MONOCLONAL ANTIBODY 2883037
MOUSE ANTI-ANKYRIN MONOCLONAL ANTIBODY - 2023663 2023663
MOUSE ANTI-ANKYRIN MONOCLONAL ANTIBODY - 2165803 2165803
MOUSE ANTI-ANKYRIN_2837234 2837234

References

Reference overviewPub Med ID
A study of the spatial protein organization of the postsynaptic density isolated from porcine cerebral cortex and cerebellum.
Yun-Hong, Y; Chih-Fan, C; Chia-Wei, C; Yen-Chung, C
Molecular & cellular proteomics : MCP  10  M110.007138  2010

Zobrazit abstrakt
21715321 21715321
Hyaluronic acid-induced lymphocyte signal transduction and HA receptor (GP85/CD44)-cytoskeleton interaction.
Bourguignon, L Y, et al.
J. Immunol., 151: 6634-44 (1993)  1992

Zobrazit abstrakt
7505012 7505012
The lymphoma transmembrane glycoprotein GP85 (CD44) is a novel guanine nucleotide-binding protein which regulates GP85 (CD44)-ankyrin interaction.
Lokeshwar, V B and Bourguignon, L Y
J. Biol. Chem., 267: 22073-8 (1992)  1992

Zobrazit abstrakt
1429559 1429559
Spectrin-based membrane skeleton: a multipotential adaptor between plasma membrane and cytoplasm.
Bennett, V
Physiol. Rev., 70: 1029-65 (1990)  1990

2271059 2271059
Capping and the cytoskeleton.
Bourguignon, L Y and Bourguignon, G J
Int. Rev. Cytol., 87: 195-224 (1984)  1983

6325363 6325363
